Print Module
Hybrid Printing Solution. The full-color inkjet print module capable of variable data printing can be combined with other printing techniques, i.e. flexo, offset and letterpress.
FULL COLOR INKJET
PRINTING SYSTEM
Color Stream Jet, A single-pass inkjet printer that prints in full-color CMYK.
The entry model CSJ-N500 Compact, the standard model CSJ-N500 Standard,
and the high-speed model CSJ-N750 are available.
You can choose the most suitable equipment according to your application.
In addition, variable dots enable high-quality digital printing.
BASIC SPECIFICATIONS
| Model | CSJ-N500 Compact | CSJ-N500 Standard | CSJ-N750 |
|---|---|---|---|
| Head type | Piezo Drop-on-demand | ||
| Printing Speed | Max.25m/min(600x1200dpi) Max.50m/min(600x600dpi) Max.50m/min(600x300dpi) |
Max.25m/min(600x1200dpi) Max.50m/min(600x600dpi) Max.100m/min(600x300dpi) |
Max.37.5m/min(600x1200dpi) Max.75m/min(600x600dpi) Max.150m/min(600x300dpi) |
| Printing Width | Max.445mm | Max.445mm | Max.445mm |
| Ink Type | UV curable ink (cyan, magenta, yellow, black) Water-based pigment (cyan, magenta, yellow, black) |
||
| Materials | Paper (non-coated, coated paper), Film, Synthetic paper, Non-woven, Foil, etc Remarks : Pre-treatment may be needed depending on the material type. |
||
| System Configuration | System Configuration Print module, Roll-to-Roll, Roll-to-Sheet | ||
MOUNTING TYPES
Roll to Roll
We provide a high-quality, simple, and more cost-effective full-color digital printing solution.
Roll to Roll / Sheet
We provide a high-quality, simple, and more cost-effective duplex full-color digital printing solution. After printing, it will be finished to roll or sheet.
ADVANTAGE
The greatest feature of digital printing is that there is no printing plate!!
This is a method of printing directly from digital data.
Variable printing
- Various expressions are possible
- Printing possible from small lots
High productivity
- Reduce time to start and finish printing
- Easier to handle than analog printers
Cost reduction
- No need for plate change or plate storage
- No paper required for setting
- Digital Printing System by CTC Japan
