Print Module
Hybrid Printing Solution.
The single-color inkjet printing module capable of variable data printing can be combined with other printing techniques, i.e. flexo, offset, and letterpress.
MONOCHROME INKJET
PRINTING SYSTEM
Stream Jet performs variable printing in black color. This is a single-pass inkjet printer.
Entry model SJ-N500 Compact, standard model SJ-N500 Standard,
With the high-speed model SJ-N750, you can choose the most suitable equipment for your application.
BASIC SPECIFICATIONS
| Model | SJ-N500 Compact | SJ-N500 Standard | SJ-N750 |
|---|---|---|---|
| Head type | Piezo drop-on-demand method | ||
| Printing Speed | Max.50m/分(600x600dpi) Max.50m/分(600x300dpi) |
Max.50m/分(600x600dpi) Max.100m/分(600x300dpi) |
Max.75m/分(600x600dpi) Max.150m/分(600x300dpi) |
| Printing Width | Max.895mm | Max.895mm | Max.895mm |
| Ink type | UV curable ink black (or cyan, magenta, yellow, white or varnish) Water-based pigment black (or cyan, magenta or yellow)MICR |
||
| Materials | Paper (non-coated, coated paper), Film, Synthetic paper, Non-woven, Foil, etc Remarks : Pre-treatment may be needed depending on the material type.. |
||
| System Configuration | Print module, Roll-to-Roll, Roll-to-Fold, Fold-to-Fold, Sheet-to-Sheet | ||
| Software | CTC Japan's original software | ||
MOUNTING TYPES
Roll to Roll
Offline Reprinting Solution.
Provides the ability to print variable data on preprinted rolls by flexo, offset, and letterpress.
Fold to Fold
Offline Reprinting Solution.
Provides the ability to print variable data on preprinted folding papers by offset presses.
Sheet to Sheet
Offline Reprinting Solution.
Provides the ability to print variable data on preprinted sheet papers by offset presses.
Intelligent Layout Software“VIPS”
Intelligent Layout Software “VIPS”Variable Information Print Software (VIPS) is a Windows® -based intelligent layout output software program, It can easily create the layout of objects such as barcodes on a Windows PC using external data such as CSV files. VIPS performs on-the-fly processing that can output data at the same time as RIP processing, thereby making printing efficiency remarkably high.
Using an optional printer driver makes it possible to print PDF files.
VIPS is only working on monochrome Stream Jet systems.
BASIS SPECIFICATIONS OF VIPS
| External data allocation | Variable-length data (CSV, TSV), Fixed-length data, Image data (tif, bmp) |
|---|---|
| Font | OpenType, TrueType font |
| Text encoding | SJIS、UNICODE |
| Main functions | Barcode generation, Auto numbering, Check digit, Imposition |
| Supported barcode, two-dimensional code |
JAN, ITF, NW-7, Industrial 2OF5, CODE39, CODE93, CODE128, UPC-A, QR code, Micro QR code, PDF417, Data Matrix, GS1 DataBar |
| Attached software | JobManager ・Deletes job files ・Calculates how many pages can be printed with a liter of ink |
| Options | Printer driver |
